2 Ton Backhoe Loader
ZT20-28
Features
Wheel Hub Reduction Axle for Enhanced Traction & Durability
The wheel hub reduction axle design improves torque transmission efficiency, increases load-bearing capacity, and reduces stress on core components, ensuring long-term durability in demanding environments.
Heavy-Duty Structure for Stable and Balanced Operation
With a 5400kg operating weight, 2550mm wheelbase, and optimized tread layout, the machine ensures excellent stability and balanced load distribution during both loading and digging operations. The 4WD system further enhances traction across different terrains.
High-Power Turbocharged Engine with Cummins Option
ZT20-28 is equipped with a 76kW turbocharged four-stroke diesel engine, delivering strong torque output and fast power response for heavy-duty loading and deep excavation tasks. The turbocharging system enhances efficiency while maintaining stable performance under continuous high-load operation.
For different market requirements, the machine supports multiple engine configurations, including Cummins (China Stage II) for proven durability and stability, as well as Yuchai engines compliant with Euro V emission standards. This flexible setup allows the machine to adapt to both cost-sensitive and high-regulation markets.
Specifications
| Overall Dimension（L×W×H） | mm | 6200*1960*2800 |
| Wheel Base | mm | 2550 |
| Wheel Tread | mm | 1580 |
| Min. Ground Clearance | mm | 290 |
| System Pressure | MPa | 18 |
| Operating Weight | Kg | 5400 |
| Max. Speed | Km/h | 28 |
| Max. Climbing Gradient | ° | 25 |
| Digging Parameters | ||
| Turning Radius | mm | 4500 |
| Max. Digging Depth | mm | 2600 |
| Max. Digging Dumping Height | mm | 2300 |
| Max. Digging Radius | mm | 4600 |
| Bucket Width | mm | 600 |
| Backhoe Capacity | m³ | 0.2 |
| Max. Digging Height | mm | 4300 |
| Max. Digging Force | kN | 28 |
| Rotary Angle Of Excavator | ° | 180 |
| Loading Parameters | ||
| Max. Dumping Height | mm | 3500 |
| Max. Dumping Distance | mm | 900 |
| Bucket Width | mm | 2100 |
| Bucket Capacity | m³ | 1m³ |
| Max. Loading Lifting Height | mm | 4300 |
| Max. Breakout Force | kN | 42 |
| Forward Shovel Action Time | S | 12 |
| Engnie | Yunnei YN38GBZ | |
| Rated Power | KW | 76 |
| Rated Speed | r/min | 2400 |
| Cylinders-Inside Diameter | 4-120 | |
| Gear Shift | F2/ R2 | |
| Steering Angle | ° | 33 |
| Tire Size | 16/70-20 | |
| Front Wheel Pressure | kPa | 250 |
| Rear Wheel Pressure | kPa | 250 |
| Fuel Tank | L | 50 |
| Hydraulic Tank | L | 50 |
| Drive Type | Four-wheel drive | |
| Variable Speed Type | Hydraulic variable speed | |
| Variable Speed Type | mm | 600 |
